DIN Z051 Round Taper Interlocks | Precision Locating Units for Injection Molds

Product Overview

DIN Z051 round taper interlocks are precision locating units used in plastic injection moulds to ensure accurate alignment between core and cavity plates during mould closing. These components are designed to absorb lateral forces, protect parting surfaces, and maintain stable mould positioning under high clamping pressure and repeated production cycles.

Key Features & Technical Advantages

• Manufactured according to DIN Z051 standard geometry

• Round taper design for reliable mould alignment

• High positioning accuracy and repeatability

• Effective protection of parting surfaces

• Suitable for high-cavity and high-cycle moulds

• Stable performance under clamping force and thermal load

• Customized / OEM / Built-to-Print manufacturing available

Applications & Industry Use

DIN Z051 round taper interlocks are widely used in:

• Multi-cavity plastic injection moulds

• Bottle cap and closure moulds

• Packaging moulds with tight alignment requirements

• Medical plastic moulds requiring consistent positioning accuracy

• High-speed injection moulds with frequent opening and closing cycles

They play a critical role in maintaining mould accuracy and long-term service life.

Mould Structure & Design Description

In injection mould assemblies, round taper interlocks are typically installed:

• Between core and cavity plates as precision locating units

• Near mould corners to resist lateral displacement

• In mould structures where parting line protection is critical

• As replaceable wear components for alignment control

All interlocks are manufactured based on standard specifications or customer drawings, including taper angle, diameter, length, and mounting interface.

Manufacturing Capability & CNC Machining

Senlan Precision specializes in high-accuracy mould component manufacturing.
Our production facility is equipped with advanced CNC machining equipment from MAKINO (Japan) and HARDINGE (USA), enabling:

• Precision CNC milling and turning

• Tight tolerance control for taper geometry

• Stable dimensional consistency for batch production

• Reliable surface finish for repeated mould operation

Each component is machined and inspected to ensure accurate fit and functional performance.

Custom Manufacturing & OEM Process

We provide complete OEM and customized manufacturing services, including:

• Built-to-Print production according to customer drawings

• Support for non-standard sizes and modified designs

• Prototype, small-batch, and volume production

• Engineering review prior to mass manufacturing

All orders follow confirmed technical specifications to ensure compatibility with customer mould designs.

Quality Control & Export Experience

With extensive experience supplying mould components to international customers, Senlan Precision applies structured quality control procedures:

• Raw material verification

• In-process dimensional inspection

• Taper accuracy and concentricity checks

• Final inspection before export packaging

Inspection reports and measurement data are available upon request.

Related Mould Components

• Mold interlocks and locating blocks

• Guide pins and guide bushings

• Precision mould wear parts

• Customized plastic injection mould spare parts

All related components are available on a custom manufacturing basis.

Technical FAQ

Q1: Are DIN Z051 interlocks available in standard sizes only?
Standard DIN Z051 sizes are supported, and customized sizes can be manufactured based on drawings.

Q2: Can these interlocks be used in high-cavity moulds?
Yes. They are commonly used in high-cavity and high-cycle injection moulds.

Q3: What materials are available?
Material selection is based on customer requirements and mould operating conditions.

Q4: Are small quantity orders accepted?
Yes. Prototype and small-batch orders are supported.

Request a Quotation

For pricing, lead time, or technical consultation regarding DIN Z051 round taper interlocks for plastic injection moulds, please submit your drawings or specifications.
Our engineering team will review your requirements and provide a detailed quotation.
