Nitrided Orvar Supreme Precision Mold Parts

Gear Components & Thread Core Inserts for Injection Molds

Product Overview

Our Nitrided Orvar Supreme precision mold parts, including gear components and thread core inserts, are engineered for high-performance plastic injection molds operating under high pressure and high cycle conditions.

Manufactured from Orvar Supreme premium hot work tool steel, these components are vacuum heat treated and surface nitrided to achieve an optimal balance of toughness, wear resistance, and dimensional stability.

They are widely used in:

• Plastic gear molds

• Cosmetic cap thread molds

• Multi-cavity packaging molds

• Automotive plastic component molds

• Medical and high-precision injection tooling

All components are produced strictly according to customer drawings (Built-to-Print / OEM manufacturing).

Material – Orvar Supreme (Premium H13 Grade)

Orvar Supreme is an advanced ESR-remelted hot work tool steel known for:

• Excellent toughness

• High thermal fatigue resistance

• Good dimensional stability

• Superior polishability

• Stable performance in high-cycle molds

Compared with standard H13 grades, Orvar Supreme provides:

• More uniform microstructure

• Better crack resistance

• Longer mold service life

Surface Treatment – Controlled Nitriding

Surface treatment plays a critical role in thread and gear components.

Our nitriding process provides:

• Increased surface hardness

• Improved wear resistance

• Reduced friction during demolding

• Enhanced resistance to plastic material abrasion

Nitriding improves surface durability while maintaining core toughness.

Typical Applications

These precision mold components are suitable for:

Plastic Thread Cores

• Cosmetic bottle caps

• Pump closures

• Medical screw-type packaging

• Rotational consumer product components

Plastic Gear Inserts

• Small transmission gears

• Electronic gear components

• Functional rotating assemblies

• Automotive interior mechanism parts

They are especially suitable for multi-cavity molds where consistency across cavities is critical.

Engineering Focus & Machining Control

Thread cores and gear inserts require extremely precise machining to ensure:

• Correct tooth geometry

• Accurate thread pitch

• Stable torque transmission

• Smooth demolding

• Reduced wear and sticking

1) Dimensional Precision

• Tolerance capability: up to ±0.002 mm

• Concentricity and axiality strictly controlled

• Stable repeatability across batches

2) Gear & Thread Profile Accuracy

• CNC machining + EDM profile forming

• Controlled flank angle and pitch accuracy

• Uniform engagement performance

3) Surface Finish

• Fine polishing available

• Low surface roughness for smooth mold release

• Reduced friction and wear

Technical Specifications

Material: Orvar Supreme
Surface Treatment: Nitriding (custom options available)
Tolerance: ±0.002 mm (customizable)
MOQ: 1 piece
Production Capacity: approx. 2000 pcs/week
Lead Time: 7–20 days (depending on complexity)
Drawing Formats: PDF, DWG, DXF, IGS, STEP

Manufacturing Equipment

• CNC turning centers

• CNC milling machines

• EDM machines

• OD grinding

• Precision finishing equipment

• CMM inspection systems

All parts undergo dimensional inspection before shipment.

Quality Control

Inspection equipment includes:

• CMM (Coordinate Measuring Machine)

• Hardness tester

• Height gauge

• Projector

• 2.5D measuring system

Quality procedures include:

• Raw material verification

• In-process inspection

• Surface hardness testing after nitriding

• Final dimensional verification

100% inspection before delivery.

OEM & Custom Manufacturing

We support:

• Built-to-Print production

• Replacement mold inserts

• Custom thread profiles

• Custom gear modules

• Small trial orders

• Long-term supply agreements

Reverse engineering service available if drawings are not provided.

Related Mold Components

To support complete mold systems, we also manufacture:

• Precision core pins

• Cavity inserts

• Multi-cavity mold components

• Slide core units

• Ejector pins and sleeves

• High-wear mold forming components

All components are compatible with international mold standards.

Why Choose Senlan Precision

• Specialized in precision mold components

• Strong experience in thread and gear mold parts

• Advanced CNC & grinding capability

• Stable supply for export mold projects

• Competitive pricing with consistent quality

• Fast technical response

Frequently Asked Questions

Q1: Why choose Orvar Supreme instead of standard H13?
Orvar Supreme offers better toughness, cleaner microstructure, and improved service life in high-cycle applications.

Q2: Can nitriding depth be customized?
Yes. Nitriding parameters can be adjusted according to wear and life requirements.

Q3: Do you support small quantity orders?
Yes. MOQ starts from 1 piece.

Q4: Can you manufacture according to samples?
Yes. Reverse engineering service is available.

Request a Technical Quotation

To receive a quotation, please provide:

• 2D / 3D drawings

• Material requirement

• Surface treatment specification

• Required tolerance

• Order quantity

Our engineering team will review your request and provide a detailed proposal within 24 hours.
