Nitrided Orvar Supreme (H13 ESR) Mold Parts | Precision Ground Core Inserts

Product Overview

The nitrided ASSAB Orvar Supreme core inserts manufactured by Senlan Precision are designed for plastic injection molds requiring high thermal stability, wear resistance, and dimensional accuracy. Precision grinding combined with controlled nitriding treatment enhances surface hardness and fatigue resistance, ensuring reliable performance in high-cycle molding environments.

Key Features & Technical Advantages

• ASSAB Orvar Supreme Tool Steel
  Premium hot-work mold steel offering excellent toughness, thermal fatigue resistance, and structural stability for demanding injection molding applications.

• Nitriding Surface Treatment
  Controlled nitriding improves surface hardness, wear resistance, and service life while maintaining core toughness.

• Precision Grinding Finish
  High-accuracy grinding ensures consistent dimensions, smooth surface quality, and stable cavity performance.

• Dimensional Stability Under Heat
  Suitable for molds operating under repeated thermal cycling and extended production runs.

• Built-to-Print / OEM Manufacturing
  All core inserts are produced strictly according to customer drawings, tolerances, and technical specifications.

Application Scenarios / Industry Applications

• Plastic injection mold core systems

• Packaging mold tooling

• Bottle cap and closure molds

• Medical packaging and syringe molds

• High-cavity and high-cycle plastic molding tools

These core inserts are widely used in molds where wear resistance, heat resistance, and long service life are critical.

Mold Structure & Design Explanation

Mold core inserts form the functional geometry of injection-molded parts and directly affect part accuracy and surface quality.
With precision grinding and nitrided surfaces, these inserts provide:

• Stable cavity dimensions

• Reduced wear and deformation

• Improved mold lifespan

• Consistent molding quality over long production cycles

The combination of Orvar Supreme steel and nitriding treatment supports reliable performance in complex mold structures.

Manufacturing Capability & CNC Machining Capacity

Senlan Precision is equipped with internationally recognized precision machining systems, including:

• Japan MAKINO CNC machining centers

• USA HARDINGE CNC turning and grinding machines

Manufacturing processes include:

• CNC milling and turning

• Precision grinding

• Controlled heat treatment and nitriding

• Dimensional inspection and surface verification

Typical capability:

• Dimensional tolerance: ±0.01 mm (or per drawing)

• Surface finish: customized based on molding requirements

Custom Development / OEM Cooperation Process

1. Review of customer drawings and application requirements

2. Material and surface treatment confirmation

3. Precision CNC machining and grinding

4. Nitriding process control and inspection

5. Final dimensional verification and documentation

6. Export packaging and delivery

This process supports new mold manufacturing, replacement inserts, and mold refurbishment projects.

Quality Control & Export Experience

• ISO9001 quality management system

• Material traceability and incoming inspection

• In-process dimensional and surface checks

• Final inspection before shipment

• Stable export experience serving global mold makers and OEM customers

Inspection reports and material certificates are available upon request.

Related Products

• Precision Mold Core Inserts

• Injection Mold Cavities

• Mold Sliders and Wear Parts

• Ejector Pins and Sleeves

• Custom CNC Machined Mold Components

Frequently Asked Questions (FAQ)

Q1: Are these core inserts standard sizes?
A: No. All parts are custom-manufactured based on customer drawings and specifications.

Q2: What is the benefit of nitriding for mold core inserts?
A: Nitriding increases surface hardness and wear resistance while maintaining internal toughness, extending mold service life.

Q3: Can grinding and nitriding be combined in one process?
A: Yes. Grinding ensures dimensional accuracy, and nitriding is applied afterward under controlled conditions.

Q4: Which industries typically use these inserts?
A: Packaging molds, medical packaging molds, and other precision plastic injection molding applications.

Request a Quotation

For nitrided ASSAB Orvar Supreme core inserts or other custom plastic injection mold parts, please contact Senlan Precision with your drawings and technical requirements.
