TiN Coated Stepped Core Pins | H13 Precision Components for Die Casting & Injection Molds

Product Overview

TiN coated stepped core pins are precision mold components used in injection and die casting molds where multi-diameter geometry, wear resistance, and dimensional stability are required. Manufactured through CNC turning, precision machining, and TiN surface coating, these components provide reliable performance under repeated molding cycles. All parts are custom produced strictly according to customer drawings and technical specifications.

Key Features & Technical Advantages

• Precision-manufactured stepped core pins for mold applications

• CNC turning combined with fine machining for stepped geometries

• TiN coating to enhance wear resistance and reduce friction

• Stable dimensional accuracy for multi-diameter functional areas

• Consistent surface quality for reliable molding and demolding

• Suitable for high-cavity and long production runs

• Fully customized / OEM / Built-to-Print manufacturing

Applications & Industries

These TiN coated stepped core pins are widely used in:

• Injection molds for packaging caps and closures

• Mold systems for bottle caps and sealing components

• Medical packaging molds and syringe-related tooling

• Precision molds requiring stepped internal or external features

They are particularly suitable for applications requiring accurate stepped geometry, surface durability, and repeatable mold performance.

Mold Structure & Design Description

Stepped core pins are installed on the core side of injection or die casting molds and are used to form internal product features with multiple diameter transitions.
Key design considerations include:

• Accurate step position and diameter control

• Smooth transitions between stepped sections

• Proper alignment and fit within mold assemblies

• Structural strength to withstand injection pressure and repeated cycles

All core pins are designed and manufactured strictly according to customer drawings to ensure correct assembly and stable mold operation.

Manufacturing Capability & CNC Machining

Senlan Precision manufactures TiN coated stepped core pins using advanced CNC machining and finishing processes.
Our production facilities are equipped with high-precision machining centers and CNC lathes from MAKINO (Japan) and HARDINGE (USA), along with other internationally recognized equipment, enabling:

• High-precision CNC turning for stepped geometries

• Stable dimensional control for multi-diameter features

• Consistent surface quality prior to coating

• Reliable repeatability across production batches

TiN coating is applied after machining and surface preparation to ensure uniform coating thickness and performance.

Custom Manufacturing & OEM Cooperation

We specialize in custom manufacturing and OEM cooperation, supporting:

• Built-to-Print production based on 2D drawings or 3D models

• Customized step dimensions and functional geometries

• Material selection and TiN coating options

• Small-batch prototyping and volume production

• Long-term supply of replacement and spare mold components

Technical communication is maintained throughout the project to ensure accurate execution of customer specifications.

Quality Control & Export Experience

With over 20 years of experience in exporting precision mold components, Senlan Precision operates a structured quality control system:

• Incoming material inspection and traceability

• In-process dimensional inspection during machining

• Coating inspection for thickness and surface condition

• Final inspection prior to shipment with complete documentation

We are experienced in international technical communication, quality requirements, and export packaging standards.

Related Mold Components

• Precision mold core pins

• Mold cavity inserts

• TiN coated mold inserts and sleeves

• Multi-cavity mold spare parts

All related products are available on a custom manufacturing basis.

Technical FAQ

Q1: Are stepped core pins manufactured strictly according to drawings?
Yes. All stepped core pins are produced strictly based on customer-provided drawings and specifications.

Q2: What is the function of TiN coating on stepped core pins?
TiN coating improves wear resistance, reduces friction, and helps maintain dimensional stability during long production cycles.

Q3: Can non-standard step designs be supported?
Yes. Custom step diameters, lengths, and transitions are fully supported.

Q4: Can these core pins be supplied as replacement parts for existing molds?
Yes. Replacement and interchangeable stepped core pins can be manufactured to match existing mold designs.

Request a Quotation

For pricing, lead time, or technical discussion regarding TiN coated stepped core pins for injection molds, please provide your drawings or technical specifications.
Our engineering team will review your requirements and provide a professional quotation accordingly.
