1.2344 Steel Core Pins & Sleeves | High Toughness Parts for Pen Moulds

Product Overview

1.2344 material mold core pins and sleeves are high-toughness mould components designed for plastic injection moulds requiring dimensional stability and long service life. Manufactured through precision CNC machining and controlled heat treatment, these components provide reliable performance in high-cycle moulding environments. All core pins and sleeves are produced strictly according to customer drawings and technical specifications.

Key Features & Technical Advantages

• Manufactured from 1.2344 hot-work tool steel

• High toughness with good resistance to thermal fatigue

• Stable hardness distribution after heat treatment

• Excellent dimensional consistency for precision moulds

• Smooth surface finish to reduce wear and friction

• Suitable for long-term and multi-cavity mould operation

• Custom design, OEM supply, and Built-to-Print production supported

Applications & Industry Use

• Bottle cap and closure injection moulds

• Packaging container and thin-wall mould systems

• Precision daily-use product moulds

• Medical consumables and disposable product moulds

• High-cavity injection moulds requiring stable core components

Mould Structure & Design Description

Core pins and sleeves are critical functional components that directly define product geometry and mould durability. In mould structures, they are used to:

• Form internal or hollow features

• Maintain accurate alignment in repeated cycles

• Withstand thermal and mechanical stress during injection

Material selection, fit tolerance, and surface condition are customized based on mould layout, cavity count, and expected service life.

Manufacturing Capability & CNC Machining Capacity

• CNC turning and milling for core geometry

• Precision grinding for diameter and concentricity control

• Controlled heat treatment for toughness optimization

• Surface finishing for wear reduction

• In-process and final dimensional inspection

• Capability for both small batch and volume production

Custom Development & OEM Cooperation Process

1. Customer drawing or sample evaluation

2. Material and hardness confirmation

3. Machining and heat treatment planning

4. Sample production and approval (if required)

5. Batch manufacturing with inspection documentation

We specialize in OEM mould components and Built-to-Print manufacturing for injection mould applications.

Quality Control & Export Experience

• Incoming raw material verification

• In-process dimensional control

• Hardness and surface inspection

• Final quality inspection prior to shipment

• Stable export supply for international mould manufacturers

Related Products (Internal Links)

• Precision Mold Core Pins

• Injection Mold Sleeves

• Custom Mold Inserts

• Multi-Cavity Mold Components

Frequently Asked Questions (FAQ)

Q1: Why is 1.2344 material suitable for mold core pins and sleeves?
1.2344 offers good toughness and thermal stability, making it suitable for injection mould components exposed to repeated thermal cycles.

Q2: Can you manufacture according to customer drawings only?
Yes. All products are produced strictly on a Built-to-Print basis using customer-provided drawings or specifications.

Q3: Are these components suitable for high-cavity moulds?
Yes. They are designed for stable performance in multi-cavity and long-running mould systems.

Q4: Do you support replacement parts for existing moulds?
Yes. Replacement core pins and sleeves can be manufactured based on drawings or samples.

Get a Quote

For custom 1.2344 mold core pins and sleeves, please provide your drawings or technical requirements.
Our engineering team will review your project and offer a detailed technical quotation.
