Precision EDM Gate Electrodes | Custom Injection Mold Components

Product Overview

Gate electrodes are precision EDM tooling components used to form gate areas, runner transitions, and flow-critical features in plastic injection molds. Senlan Precision manufactures custom gate electrodes strictly based on customer drawings, ensuring stable EDM performance, accurate gate geometry, and consistent mold cavity quality across single- and multi-cavity injection mold systems.

Key Features & Advantages

• Precision-machined electrodes for gate and runner EDM processing

• Stable electrical discharge performance for controlled material removal

• Accurate replication of gate geometry and flow profiles

• Suitable for tight-tolerance injection mold components

• Consistent performance in multi-cavity mold configurations

• Custom materials and dimensions available

• Built-to-Print manufacturing with strict dimensional control

Applications / Industry Use

• Plastic bottle and closure injection molds

• Bottle cap and flip-top cap mold tooling

• Medical consumables and syringe mold systems

• Cosmetic and daily packaging injection molds

• Multi-cavity and high-output mold designs

Mold Structure & Design Description

Gate electrodes are used during EDM machining to shape gate entrances, runner connections, and flow-sensitive areas within injection mold cavities. The electrode geometry directly affects melt flow balance, gate appearance, and mold consistency. Precision-designed gate electrodes help minimize EDM defects, ensure uniform cavity formation, and support stable mold performance during long production cycles.

Manufacturing Capability & CNC Machining

Senlan Precision operates a dedicated machining workflow for gate electrode manufacturing, combining CNC machining and EDM preparation processes.

Manufacturing capabilities include:

• CNC milling and turning for complex electrode profiles

• Precision grinding for flatness and alignment control

• EDM electrode profiling for gate-specific geometries

• Tight tolerance control for repeatable EDM machining results

• Surface preparation to ensure consistent spark discharge

High-precision machining equipment from MAKINO and HARDINGE supports stable accuracy and repeatability for custom mold components.

Custom Development / OEM Cooperation Process

1. Customer provides 2D drawings or 3D mold data

2. Engineering review of gate structure and EDM requirements

3. CNC machining and electrode profiling

4. Dimensional inspection and quality verification

5. Final approval and export packaging

6. Shipment according to customer logistics requirements

All projects follow a Built-to-Print OEM manufacturing model.

Quality Control & Export Experience

• Incoming material inspection

• In-process dimensional verification

• Final inspection before shipment

• Consistency control for batch and multi-cavity projects

• Extensive experience supplying mold components to international customers

Quality management is executed under standardized industrial manufacturing procedures.

Related Products

• EDM copper electrodes for mold cavities

• Mold core inserts and cavity inserts

• Injection mold gate inserts

• Multi-cavity mold components

• Custom CNC machined mold tooling parts

FAQ – Technical & Purchasing

Q1: Are gate electrodes standard or custom parts?
Gate electrodes are custom-manufactured based on mold drawings and gate design requirements.

Q2: Can these electrodes be used for multi-cavity molds?
Yes. They are suitable for high-cavity molds requiring consistent gate geometry across cavities.

Q3: What materials are available for gate electrodes?
Material selection depends on EDM performance requirements and customer specifications.

Q4: What is required to request a quotation?
Technical drawings, application details, quantity, and tolerance requirements.

Request a Quote

For technical evaluation and pricing, please submit your drawings and mold application details.
Our engineering team will provide a professional manufacturing solution tailored to your injection mold project.
