High-Tolerance Multi-Cavity Mold Inserts | Fine Surface Grinding (±0.002mm)

Product Overview

Multi-cavity customized plastic mould parts are critical components for high-output injection molding systems where dimensional consistency and surface quality must be maintained across all cavities. Senlan Precision manufactures built-to-print mould components with fine surface grinding to ensure stable fitting, uniform part geometry, and reliable performance in multi-cavity mould applications.

Key Features & Advantages

• Designed for multi-cavity injection mould systems

• Fine surface grinding for stable fitting and surface consistency

• High repeatability across all cavities

• Tight dimensional control for long-term mould stability

• Suitable for high-volume production moulds

• Custom / OEM manufacturing strictly according to drawings

• Compatible with various mould steel materials as specified

Applications / Industry Use

• Bottle cap and closure moulds

• Packaging mould systems with multiple cavities

• Medical consumable injection moulds

• Cosmetic and daily-use plastic packaging moulds

• High-output injection molding tooling

Mould Structure & Design Description

Multi-cavity mould parts require precise dimensional alignment between cavities to ensure consistent filling, cooling, and part ejection. Fine surface grinding is applied to critical contact and fitting surfaces to improve flatness, parallelism, and surface integrity. These processes help reduce mould wear, improve assembly accuracy, and maintain stable production over extended cycles.

Manufacturing Capability & CNC Machining

Senlan Precision is equipped with high-precision machining and finishing equipment to support multi-cavity mould part production. Advanced machining centers from MAKINO and precision equipment from HARDINGE are used to achieve consistent machining accuracy and controlled surface quality.

Manufacturing processes include:

• CNC milling and turning

• Precision surface grinding

• Fine finishing for critical fitting areas

• EDM processing (if required by design)

• Dimensional inspection and verification

Custom Development / OEM Cooperation Process

1. Customer submits drawings or 3D models

2. Engineering review of cavity layout and tolerance requirements

3. Machining and surface grinding process planning

4. Precision manufacturing and finishing

5. Quality inspection before shipment

6. Export packaging and delivery

All parts are produced under a Built-to-Print OEM cooperation model.

Quality Control & Export Experience

• Incoming raw material inspection

• In-process dimensional and surface inspection

• Final inspection prior to shipment

• Standardized quality management procedures

• Experience supplying multi-cavity mould components to international customers

Related Products

• Multi-cavity mould core inserts

• Precision cavity inserts and sleeves

• Thread cores for closure moulds

• Mold plates and custom mould components

• High-precision mould parts with surface grinding

FAQ – Technical & Purchasing

Q1: Why is surface grinding important for multi-cavity mould parts?
Surface grinding improves flatness and fitting accuracy, helping maintain consistency across all cavities.

Q2: Do you provide mould design services?
No. All parts are manufactured strictly according to customer-provided drawings (Built-to-Print).

Q3: Can different cavity tolerances be controlled individually?
Yes. Tolerance control is performed according to drawing requirements for each cavity feature.

Q4: Are small batch or trial orders accepted?
Yes. Both prototype and serial production are supported.

Request a Quote

Please provide technical drawings, material specifications, tolerance requirements, and cavity quantity.
Our engineering team will review your request and provide a technical quotation accordingly.
